Ever since I started my programming journey I have been amazed at how we achieved human-computer "communication". The ability to write programs instead of crafting different devices hardcoded for a single purpose was one of the biggest leaps forward technology has ever faced. If you are a curious person, this of course makes you wonder "But how?". Well, that is an incredibly broad, interesting, and complicated topic. But what I can and will be teaching you if you keep reading is the basics of a certain type of programming languages, Interpreted Languages.

For this example/tutorial it is assumed that you have moderate knowledge of at least Python, which is the language we will be using in order to help most people understand the concepts rather than focusing too much on the code, even though it will of course be present throughout all the explanations.

What is a logic evaluator?

It is a fairly simple interpreter since it just takes a mathematical expression that evaluates to true or false given the condition it represents, e.g: !A | B will only return true if either the variable B or the opposite of A is true. Even this seemingly simple example involves:

• Two variables: A and B.
• Two operators: Logical OR | and logical NOT !.

We will also add pretty printing in the form of a truth table to better visualize our work. It would look something like this:

A	B	!A | B
T	T	T
T	F	F
F	T	T
F	F	T

The first two columns represent respectively the values of A and B, while the third column shows the resulting value after evaluating the expression for that specific combination of values.

Interpreter

Most interpreters follow the same three steps or parts, the lexer/tokeniser, the parser, and the evaluator. For this we will have the following file structure:

.
├── evaluator.py
├── lexer.py
├── main.py
└── parser.py

The Lexer

You can see the full code of lexer.py

1. Concept

The simplest way to describe this step is that it takes the raw text of the input and breaks it down into the actual parts of your language. In this case, it would be variables and operators, but in a general-purpose language, it would also have to extract keywords (several text characters) and understand them as a single token, and other nuances like treating numbers or special symbols differently, etc etc.

2. Types of Tokens

As we just mentioned, we need to define the Tokens that exist in our language, we will just define an Enum with each of them (this is considered good practice instead of repeating strings everywhere):

class TokenType(Enum):
    LParen = "LParen" # (
    RParen = "RParen" # )
    NotOp = "NotOp" # !
    AndOp = "AndOp" # &
    OrOp = "OrOp" # |
    ImpliesOp = "ImpliesOp" # ->
    BiconditionalOp = "BiconditionalOp" # <->
    Variable = "Variable" # A-Z Upper case
    Eof = "Eof" # The endline character (depends on stdin)

And we should also define a class for the shape of each Token to help us later. It will hold both its type and its "lexeme" (its string form):

@dataclass(frozen=True)
class Token:
    type: TokenType
    lexeme: Optional[str] = None

3. Lexing

Now the actual tokenizing. The lexer class will hold both the input string (the logical formula) and the current position as we move forward through the formula after each token (since as you have noticed there are two operators that respectively span two and three characters, the Implies and the Biconditional).

class Lexer:
    def __init__(self, input: str) -> None:
        self._input = input
        self._position = 0

    def _peek(self, offset: int = 0) -> Optional[str]: ...

    def _advance(self, count: int = 1) -> None: ...

    def lex(self) -> list[Token]: ...

As you can already notice we only need to make use of three methods. The two private ones, _peek() and _advance(), are helpers for operations repeated several times throughout the actual lexing performed at lex().

1. Peek: Checks whether the character at a certain offset from the current position exists, and if that's the case it returns it. If not, it just returns None. This is used in longer than one character tokens, so if we encounter the first character, we can check whether the following match the expected for the expected token, and if they do not it is an invalid character so we just raise an error.

   def _peek(self, offset: int = 0) -> Optional[str]:
       if self._position + offset < len(self._input):
           return self._input[self._position + offset]
       return None


2. Advance: Simply moves the current position forward by a certain amount.

   def _advance(self, count: int = 1) -> None:
       self._position += count


3. Lex: The main method that performs the actual lexing. It will return the list of tokens that can be used by the parser.

   def lex(self) -> list[Token]:
       tokens: list[Token] = []
       while self._position < len(self._input):
           current_char = self._input[self._position]
           match current_char:
               ...


   The first thing we do is create an empty list of tokens, and then we loop through the input string, extracting each individual token into that list until we reach the end, at which point we return the list. Let's break it down a bit:

   • If the character is a space, we just advance the position and continue to the next character:

     case char if char.isspace():
         self._advance()


   • If the character is any of the following characters: (, ), !, &, | the same process of creating a token of that type and advancing the position is performed. Since they are single character tokens there is no need to check for anything else:

     case "(":
         tokens.append(Token(TokenType.LParen, "("))
         self._advance()
     # ...
     # Same for the other characters
     # ...
     case "|":
         tokens.append(Token(TokenType.OrOp, "|"))
         self._advance()


   • Now the four interesting cases left: -> and <->, as well as the default and variables:

     • If the character is - it indicates we are about to encounter the Implies operator, right? So instead of creating that token right away we make use of the _peek() method I told you would be helpful to see if indeed the next character is a >. If so, we create the token and advance the position. If not, we just raise a helpful error since we have available information like our current position and character:

       case "-":
           if self._peek(1) == ">":
              tokens.append(Token(TokenType.ImpliesOp, "->"))
              self._advance(2)
           else:
               raise Exception(
                   f"Lexer error: Unexpected character '{current_char}' at position {self._position}. Expected '->'."
               )


     • If the character is < it indicates we are about to encounter the Biconditional, but yet again we need to make the due checks similarly to Implies:

       case "<":
           if self._peek(1) == "-" and self._peek(2) == ">":
               tokens.append(Token(TokenType.BiconditionalOp, "<->"))
               self._advance(3)
           else:
               raise Exception(
                   f"Lexer error: Unexpected character '{current_char}' at position {self._position}. Expected '<->'."
               )


     • If the character is any of A-Z we create a token of type Variable and advance the position:

       case char if "A" <= char <= "Z":
           tokens.append(Token(TokenType.Variable, char))
           self._advance()


     • Now if any character hasn't fallen in any of the above cases, it means that it is an invalid character, so we again raise an error:

       case _:
           raise Exception(
               f"Lexer error: Unexpected character '{current_char}' at position {self._position}."
           )


   • The only thing left is to append the corresponding EOF token at the end of the list and return it:

     tokens.append(Token(TokenType.Eof))
     return tokens


That is about it. We have now created the list of tokens that can be used by the parser. It is important to notice that this way of checking characters may seem straightforward when presented to you like this, but the importance of the _peek() method is rather significant. You can imagine how in a more complex lexer, maybe for a general-purpose programming language for example, you would have to check entire lines or in the next line even.

Also notice how storing the position correctly besides helping on the peeking allows us to give a lot more precise error messages, which again would be a lot more complex for a general-purpose language. And see how for example when raising an error in the cases of the Implies and Biconditional operators we knew the apparently misplaced character was part of these tokens, we suggest that could be the typo that has been made.

The Parser

You can see the full code of parser.py

1. Concept

This second step will take the list of tokens we just generated and turn it into the corresponding nodes of the abstract syntax tree (AST), which simply means representing the tokens that form the parsed expression accordingly nested within each other in a list, this will be more clear as we move forward. It is the trickiest part. Taking the example we are building, there are different types of operators which determine things like the order in which they should be evaluated.

2. Types of AST Nodes

Different operators have different levels of precedence, meaning they need to be evaluated first, and since we just have tokenized the raw expression we need to now turn it into the ordered list of nodes that can be used to evaluate the expression correctly. In our specific example the precedence would be as follows:

1. Not: !
2. And: &
3. Or: |
4. Implies: ->
5. Biconditional: <->

So in an expression like !A & B | C -> D <-> E, the parser must parse !A first, then &, then |, and so on to build the AST correctly. This leads us to the concept of associativity, which determines how operators of the same precedence (which in this case can only happen if it is the same operator) are grouped together:

• Left-associative: The operator is evaluated before the operands, grouped from left to right. In the implementation this is represented by a while loop.
  • Example: A & B & C -> And(left=And(left=Var(name='A'), right=Var(name='B')), right=Var(name='C'))
• Right-associative: The operator is evaluated after the operands, grouped from right to left. In the implementation this is represented by a conditional instead.
  • Example: A -> B -> C -> Implies(left=Var(name='A'), right=Implies(left=Var(name='B'), right=Var(name='C')))

The right-associative operators are Not and Implies, while the left-associative operators are And, Or and Biconditional.

Also, since as you must have noticed all operators besides Not hold a left and right branch on the node tree, we should also define a class for the shape of each node (all inheriting from Expression so they can all be treated as such) to help us later. They will hold both branches or in the case of Variables and Not simply the name and the inner expression respectively:

class Expression:
    pass

@dataclass(frozen=True)
class Var(Expression):
    name: str

@dataclass(frozen=True)
class Not(Expression):
    expression: Expression

@dataclass(frozen=True)
class And(Expression):
    left: Expression
    right: Expression

@dataclass(frozen=True)
class Or(Expression):
    left: Expression
    right: Expression

@dataclass(frozen=True)
class Implies(Expression):
    left: Expression
    right: Expression

@dataclass(frozen=True)
class Biconditional(Expression):
    left: Expression
    right: Expression

3. Parsing

Just as we did with the lexer we are going to take a look at each of the helper methods of the Parser class, though it is a lot more complex due to mutual recursivity between the different _parse_*() methods. Let's take a look at the helpers first:

1. Consume: Since now we have individual tokens, we will be moving linearly through the list. This method will consume the next token and return it, raising an error if it is not of the expected type:

   def _consume(self, expected_type: TokenType) -> None:
       if self._peek().type == expected_type:
           self._position += 1
       else:
           raise Exception(
               f"Parser error: Expected {expected_type} but found {self._peek().type}"
           )


2. Peek: Similar to the _peek() method of the lexer, though this method will only check the current position and not the next one. It will return the token at the current position if it exists, and EOF otherwise:

   def _peek(self) -> Optional[Token]:
       if self._position < len(self._tokens):
           return self._tokens[self._position]
       return Token(TokenType.Eof)


3. Parse: This is the main method that performs the actual parsing. It will return the AST expression that can be used by the evaluator. It works by using a bunch of private parsing helpers for each type of token that are mutually recursive one after the other. What this means is that, following the order of precedence, each parsing operation will call the next until the end of the expression:

   parse()
   └── _parse_biconditional()
       └── _parse_implies()
           └── _parse_or()
               └── _parse_and()
                   └── _parse_not()
                       └── _parse_primary()


   This is a bit counterintuitive since it may seem "upside down", but it's the correct order. The parsing process starts with the lowest precedence operator (_parse_biconditional), which calls the function for the next higher precedence operator (_parse_implies), and so on, until it reaches the highest precedence operators (_parse_primary and _parse_not). This recursive descent approach naturally handles the order of operations by delegating to functions for higher- precedence expressions.

   def _parse_primary(self) -> Expression:
        token = self._peek()
        if token.type == TokenType.Variable:
            self._consume(TokenType.Variable)
            if token.lexeme is None:
                raise Exception("Parser error: Variable name is missing.")
            return Var(token.lexeme)
        elif token.type == TokenType.LParen:
            self._consume(TokenType.LParen)
            expr = self._parse_biconditional()
            self._consume(TokenType.RParen)
            return expr
        else:
            raise Exception(
                f"Parser error: Expected variable or '(' but found {token.type}"
            )

    def _parse_not(self) -> Expression:
        if self._peek().type == TokenType.NotOp:
            self._consume(TokenType.NotOp)
            return Not(self._parse_not())
        return self._parse_primary()

    def _parse_and(self) -> Expression:
        left = self._parse_not()
        while self._peek().type == TokenType.AndOp:
            self._consume(TokenType.AndOp)
            right = self._parse_not()
            left = And(left, right)
        return left

    def _parse_or(self) -> Expression:
        left = self._parse_and()
        while self._peek().type == TokenType.OrOp:
            self._consume(TokenType.OrOp)
            right = self._parse_and()
            left = Or(left, right)
        return left

    def _parse_implies(self) -> Expression:
        left = self._parse_or()
        if self._peek().type == TokenType.ImpliesOp:
            self._consume(TokenType.ImpliesOp)
            right = self._parse_implies()
            left = Implies(left, right)
        return left

    def _parse_biconditional(self) -> Expression:
        left = self._parse_implies()
        while self._peek().type == TokenType.BiconditionalOp:
            self._consume(TokenType.BiconditionalOp)
            right = self._parse_implies()
            left = Biconditional(left, right)
        return left

    def parse(self) -> Expression:
        expr = self._parse_biconditional()
        if self._peek().type != TokenType.Eof:
            raise Exception("Parser error: Unexpected tokens remaining.")
        return expr


The Evaluator

You can see the full code of parser.py

1. Concept

Congratulations! We have already gone through basically all the implementation. Now we just have to evaluate the already parsed expression and print the result. We will not be getting into the details of printing, but evaluating since we already have the AST is fairly easy. Given that we will have already created the different assignments, meaning the different possible combinations of the given variables, when generating the table (if you are curious look at the source code), we can just create a general evaluate() method that will take the expression and the variables and return the result of each logical computation.

2. Evaluating the AST

To achieve this it is as simple as pattern matching the different branches of the tree, and applying each operation recursively.

class Evaluator:
    def __init__(self, assignments: dict[str, bool]) -> None:
        self._assignments = assignments

    def evaluate(self, expr: Expression) -> bool:
        match expr:
            case Var(name):
                return self._assignments[name]
            case Not(expression):
                return not self.evaluate(expression)
            case And(left, right):
                return self.evaluate(left) and self.evaluate(right)
            case Or(left, right):
                return self.evaluate(left) or self.evaluate(right)
            case Implies(left, right):
                return not self.evaluate(left) or self.evaluate(right)
            case Biconditional(left, right):
                return self.evaluate(left) == self.evaluate(right)
            case _:
                raise Exception("Evaluation error: Unknown expression type.")

In the unlikely case that an error has come this far in the process, we will just raise it with an adequate message as always. You may have noticed that this is a pattern repeated constantly throughout the whole codebase: checks everywhere and as informative as possible error messages, even though no errors should be able to reach this point.

You can see the main file for the actual user interaction and coupling the three parts together main.py just for curiosity, but we have already covered the entire implementation of the interpreter.

Conclusion

We have now reached the end of the tutorial! And although it is not the most complex example, it still shows the power of the interpreter and how it can be used to evaluate any kind of computation.

As always, thanks for reading and if you have any questions or comments feel free to reach out to me on X/Twitter or by mail at davidvivarbogonez@gmail.com, I am always open to criticism, just like I hope you did by reading this, I am always trying to learn and improve.

Also, as a bonus, you can find a version of this project in F# in github.com/4ster-light/f-logic, for those who are interested and wanna expand their learning further, you will find interesting ways that Functional Programming helps in this kind of problems, as well as algebraic data types, discriminated unions, pattern matching, etc.
